The SEYOUN SYT917 is a heavy-duty all-steel radial commercial tire purposefully engineered for trailer tires operating in severe off-road environments. Featuring a massive 20PR reinforced ply rating and an aggressive high-void block profile, the SYT917 is built to survive where standard line-haul trailer tires fail. It delivers uncompromising lateral stability, relentless self-cleaning traction in mud or sand, and extreme structural defense against rock puncturing. This tire is the definitive investment for fleets looking to minimize heavy equipment downtime and dramatically drop annual tire replacement costs in the world’s toughest terrains.
SYT917 Tread Pattern DesignThe SYT917 boasts an optimized matrix of extra-large, interconnected center lug blocks interspersed with deep transversal lugs. When rolling through soft mud, loose gravel, or deep sand, this rugged architecture bites deeply into the terrain, ensuring the free-rolling trailer maintains steady alignment and prevents dangerous trailer sway or lateral slippage under maximum load.
The tread utilizes wide, dynamic stone-ejecting channels that clear debris as the tire rotates. This advanced layout actively flushes out thick mud and repels trapped stones, effectively preventing severe stone-drilling into the steel belts, securing the structural casing from early fatigue.
Engineered specifically for mining and construction fields, the SYT917 is integrated with a proprietary, high-density compounding matrix. This specialized rubber armor offers industry-leading protection against severe cutting, surface chipping, and chunking caused by jagged rocks and debris, drastically increasing total removal mileage in mixed-service applications.
| Pattern | Size | PR | LI&SS | Overall Diameter(mm) |
Load Capacity(kg) | Inflation Pressure(kpa) | Section Width (mm) |
Standard Rim (inch) |
Tread Depth (mm) | |
| Single | Dual | |||||||||
| SYT917 | 315/80R22.5 | 20 | 167D | 1,080 | 4,125 | 3,750 | 900 | 312 | 9.00 | 23 |
| Available Sizes | ||||||
| 6.50R16LT | 9.00R20 | 11R24.5 | 13R22.5 | 245/70R17.5 | 295/60R22.5 | 295/75R22.5 |
| 7.00R16LT | 10.00R20 | 12.00R20 | 215/75R17.5 | 245/70R19.5 | 275/80R22.5 | 315/70R22.5 |
| 7.50R16LT | 11.00R20 | 12.00R24 | 225/80R17.5 | 265/70R19.5 | 295/80R22.5 | 385/65R22.5 |
| 8.25R16LT | 11R22.5 | 12R22.5 | 235/75R17.5 | 275/70R22.5 | 315/80R22.5 | 205/85R16LT |
1.High Wear Resistance 4.Long Mileage Performance
Special tread compound design extends tire life and reduces cost per km. Optimized footprint distbution promotes even wear and longer mileage.
2.Strong Traction Performance 5.Fuel Saving
Deep grooves and block design provide excellent grip on wet and dey roads. Low roling resistance design helps reduce fuel consumption.
3.High Load Capacity 6.Safe & Reliable
Reinforced carcass structure enpures high load capacity and durabllity. Superior stablity and braking performance ensure driving safety.
As a rubber production combined with steel and other materials, tires can be eroded slowly by chemicals, oil, heat, and ozone. The main raw materials of tires include natural rubber and synthetic rubber from petroleum products, so tires exposed to high temperatures heat or fire sources will cause fires that are difficult to extinguish.
Tires should be stored in a cool, dry, clean warehouse to prevent rain, dust, and light. Tires should be placed away from electric generators/motors and sources of heat such as hot pipes. Storage surfaces should be clean and free of grease, gasoline, diesel fuel, or other substances that can deteriorate the rubber. Please rotate tires every month if they are upright in storage. If tires have to be stored outdoors, the place should be:
Improper storage can damage your tires in ways that may not be visible and can lead to a
failure resulting in serious personal injury or death.
Avoid mixing with trucks transporting oil and chemicals. Tire transport vehicles should be equipped with adequate fire equipment. When using a forklift to handle truck tires, install the correct accessories for the forklift, such as tire stackers, tire handlers, etc. Any improper handling ways may cause damage to the tire. For example, the keen-edged forks can bring damage to the bead if you use the forklift without proper accessories.
Proper mounting procedures must be followed or sudden tire destruction, personal injury or death may result. Tire mounting must be done only by personnel trained, supervised and equipped according to local regulations and following the processes requirement of the industries. Always inflate tire/rim assembly in an approved safety cage or equivalent restraining device
